Deploy to Cloudrun with Terraform and Github Actions

· André Luiz Tiago Soares

cover

Intro

This post is going to be about how to setup a basic CI/CD pipeline for Google Cloud Run, by using Terraform (or OpenTofu) for Infrastructure as Code (IaC), and Github Actions for CI/CD.

Here are some advantages of deploying Cloud Run apps like this:

  • Deploy any supporting cloud resources along with you app
  • Single deployment step (terraform plan & terraform apply)
  • Easy environment replication
  • Keep your Cloud Infrastructure organized
  • Works great for applications composed by multiple Cloud Run services
  • Simplify you CI/CD pipelines

First I’ll focus just on the Terraform configurations and just deploying the enviroment locally from the command line. And then on how to automate that with Github Actions.

If you don’t want to implement everything from scratch, I have also made this pipeline available as public repository template in my Github. It takes about 20 minutes to configure and also deploys a Firestore database and Secret Manager secret with preconfigured permissions.

Prerequisites

Terraform backend configuration and providers

For providers, we’re going to need:

  • docker, to build and push images
  • google to deploy Artifact Registry repositories and Cloud Run services

For the variables, I recommed setting things up the same way I usually do. This will make it easier to replicate configs between environments later.

I always like to include, in all my GCP configs:

  • project_id and region for replication between environments
  • service_name and env for consistent naming conventions and namespacing of resources

We are also going to need:

  • gcloud_access_token for docker authentication

I also don’t set the backend configuration specification, and instead prefer to pass those through --backend-config. This is also make replication between environments easier.

When we get to the Github Actions part this all of this is going to make sense.

Here is what it looks like:

# 1.0 BACKEND
terraform {
 backend "gcs" {}
 required_providers {
	 docker = {
		 source  = "kreuzwerker/docker"
		 version = "3.0.2"
	 }
 }
}

# 1.1 VARIABLES

variable "project_id" {
  description = "Google Cloud Project ID"
}

variable "region" {
  description = "Google Cloud region"
  default     = "us-west1"
}

variable "service_name" {
  description = "Name of the service. Defines the resource names of both the AR repository and Cloud Run service."
}

variable "env" {
  description = "Name of the environment (e.g dev or prod)"
  default     = "dev"
}

variable "gcloud_access_token" {
	description = "Access token of the gcloud CLI. Needed for docker auth"
	sensitive = true
}

# 1.3 PROVIDERS
provider "google" {
  project = var.project_id
  region  = var.region
}

provider "docker" {
	host = "unix:///var/run/docker.sock"
	registry_auth {
	  address = "${var.region}-docker.pkg.dev"
	  username = "oauth2accesstoken"
	  password = var.gcloud_access_token
	}
}

Take notice on how the the gcloud_access_token was used to configure the authentication for docker.

Build and push a docker image to Artifact Registry with Terraform

To build and push the image from within Terraform, we are going to first create our GAR repository with google_artifact_registry_repository, then build the image with docker_image and the push it with docker_registry_image

# 2 RESOURCES

# 2.1 ARTIFACT REGISTRY REPO
resource "google_artifact_registry_repository" "repo" {
  location      = var.region
  repository_id = "${var.service_name}-${var.env}"
  format        = "DOCKER"
}

# 2.2 BUILD AND PUSH IMAGE
resource "docker_image" "build_image" {
  name = "${var.region}-docker.pkg.dev/${var.project_id}/${var.service_name}-${var.env}/${var.service_name}-${var.env}:1.0"

  build {
    context = "${path.cwd}"
  }
}

resource "docker_registry_image" "image" {
  name = docker_image.build_image.name
}

Now, to deploy this configuration, first make sure you have gcloud CLI configured, and then make sure it is properly authenticated.

gcloud auth login

And:

gcloud auth application-default login

Both commands will start an oauth flow to authenticate the gcloud CLI.

Next create a .tvars file like this example:

project_id = "your-gcp-project-id"
region = "us-west1"
env = "dev"
service_name = "dockertest"

Then, on the directory where you main.tf is located, initialize terraform.

tofu init \
--backend-config "bucket=your-tf-state-bucket" \
--backend-config "prefix=your-tf-state-prefix"

Make sure docker is running. In WSL2 this can be done with:

sudo service docker start

Finally, deploy your infrastructure.

terraform apply \
--var-file .tfvars \
--var "gcloud_access_token=$(gcloud auth print-access-token)"

So far, this will deploy an Artifact Registry repository, build a Docker image and push it to the previously deployed repository. The next step is to create the Cloud Run service and have it use the image we just pushed.

Deploying the Cloud Run service

Next, just include the following in your main.tf.

# 2.3 SERVICE ACCOUNT

resource "google_service_account" "sa" {
  account_id   = "${var.service_name}-${var.env}-svc"
  display_name = "Service account for cloud run"
}

# 2.4 SERVICE

# Define a Google Cloud Run service
resource "google_cloud_run_service" "app" {
  name     = "${var.service_name}-${var.env}"
  location = var.region

  template {
    spec {
      containers {

        image = docker_registry_image.image.name
        env {
          name  = "ENV"
          value = var.env
        }
      }
      service_account_name = google_service_account.sa.email
    }
  }
}

Now, redeploy the configuration with:

terraform apply \
--var-file .tfvars \
--var "gcloud_access_token=$(gcloud auth print-access-token)"

Terraform should also create a Cloud Run service that uses the image that was pushed to the repository. Right now, we are already at the point where we can deploy everything we need from the local terminal. Now, let’s move on to automating these steps with Github Actions.

Github Actions CI/CD pipeline

Since Terraform is doing most of the heavy lifting, specially by building and pushing our docker image, our Github Workflow file is ends up actually being pretty simple. It is barely an “wrapper” script that just call our terraform commands.

The workflow file below will also support deployng to the prod and dev environments by pushing to the main and dev branches respectively.

Add this to .github/workflows/deploy.yaml

name: Build and Deploy to Cloud Run through OpenTofu

on:
  push:
    branches: [ "main", "dev" ]

jobs:
  deploy:
    permissions:
      contents: 'read'
      id-token: 'write'

    runs-on: ubuntu-latest
    environment:  ${{ fromJSON('["dev", "prod"]')[github.ref_name == 'main'] }}
    steps:
      - name: Checkout
        uses: actions/checkout@v2

      - name: Google Auth
        id: auth
        uses: 'google-github-actions/auth@v2'
        with:
          token_format: 'access_token'
          workload_identity_provider: '${{ vars.WIF_PROVIDER }}'
          service_account: '${{ vars.WIF_SERVICE_ACCOUNT }}'

      - name: Tofu Setup
        uses: opentofu/setup-opentofu@v1

      - name: Tofu Init
        run: tofu init --backend-config "bucket=${{ vars.TF_BUCKET }}" --backend-config "prefix=${{ vars.TF_PREFIX }}"

      - name: Tofu Select Workspace
        if: ${{ env.tf_workspace != '' }}
        run: tofu workspace select --or-create ${{ vars.tf_workspace }}

      - name: Tofu Plan
        run: |
          tofu plan \
          --var "project_id=${{ vars.PROJECT_ID }}" \
          --var "region=${{ vars.REGION }}" \
          --var "service_name=${{ vars.SERVICE }}" \
          --var "env=${{ vars.ENV }}" \
          --var "gcloud_access_token=${{ steps.auth.outputs.access_token }}" \
          --out tofu-plan

      - name: Tofu Apply
        run: tofu apply tofu-plan

Here is a quick overview on what’s happening:

  1. Checkout
  2. Authenticate the gcloud cli using Workload Identity Federation.
  3. Setup, initialize and select workspace with OpenTofu (for pratical purposes, it is the same thing as Terraform)
  4. Plan and deploy our application (which will include the docker build and push steps

When you commit and push it to your repository, at this point, the deployment will fail. There are two reasons for that.
The first error we are going to get is in the ‘Google Auth’ step, because we still didn’t gave permission for Github Actions to manage infrastructure in our GCP account. The second reason is because we have some repository environment variables to set.

We are going over these 2 things next.

Configuring Workload Identity Federation (WIF) for Github Actions

To configure WIF, we have to basically do 2 things:

  1. Create Service Account for Github Actions to use and deploy resources
  2. Use a WIF pool to tell GCP that our repository workflows are authorized to use that Service Account

I’m not going into much depth on the inner workings of WIF. You can read more about it here. Instead, here is how you set it up as quickly as possible using the gcloud CLI. You can use the same service account and WIF provider if you intend to deploy both prod and dev environments in the same GCP project. But if you intend to isolate your enviroments in different projects (which I recommend) you are going to have to run these steps twice, once for each enviroment / project.

Create a Service Account

$WIF_SERVICE_ACCOUNT_NAME=devops-svc
gcloud iam service-accounts create $WIF_SERVICE_ACCOUNT_NAME \
    --description="Devops account for Cloud Run projects" \
    --display-name="Devops Service Account for Cloud Run"

Create a WIF pool

gcloud iam workload-identity-pools create "ci-cd" \
  --location="global" \
  --display-name="CI/CD"

Create a WIF provider

gcloud iam workload-identity-pools providers create-oidc "github-actions" \
  --location="global" \
  --workload-identity-pool="ci-cd" \
  --display-name="Github Actions" \
  --attribute-mapping="google.subject=assertion.sub,attribute.repository=assertion.repository" \
  --issuer-uri="https://token.actions.githubusercontent.com"

You can then, print the workload identity pool name with:

gcloud iam workload-identity-pools describe ci-cd --location global

Finally, give Github Actions access to impersonate this account.

$PROJECT_ID=your-gcp-project-id
$GH_REPO=your-org/your-repo
gcloud iam service-accounts add-iam-policy-binding "${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
  --project="${PROJECT_ID}" \
  --role="roles/iam.workloadIdentityUser" \
  --member="principalSet://iam.googleapis.com/${WIF_POOL}/attribute.repository/${GH_REPO}"

So, at this point, Github Actions can impersonate that account, but the account itself has no permissions within the project. So we have to give it some. The command below will give the account admin access to Artifact Registry, Cloud Run, IAM Service Accounts and Project IAM.

gcloud projects add-iam-policy-binding $PROJECT_ID \
    --member="serviceAccount:${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
    --role="roles/artifactregistry.admin" \
	--condition=None

gcloud projects add-iam-policy-binding $PROJECT_ID \
    --member="serviceAccount:${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
    --role="roles/iam.serviceAccountUser" \
	--condition=None

gcloud projects add-iam-policy-binding $PROJECT_ID \
    --member="serviceAccount:${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
    --role="roles/iam.serviceAccountAdmin" \
	--condition=None

gcloud projects add-iam-policy-binding $PROJECT_ID \
    --member="serviceAccount:${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
    --role="roles/resourcemanager.projectIamAdmin" \
	--condition=None

gcloud projects add-iam-policy-binding $PROJECT_ID \
    --member="serviceAccount:${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
    --role="roles/run.admin" \
	--condition=None

The account also needs access to manage state in the TF bucket

TF_BUCKET=your-terraform-bucket
gcloud storage buckets add-iam-policy-binding gs://${TF_BUCKET} \
        --member="serviceAccount:${WIF_SERVICE_ACCOUNT_NAME}@${PROJECT_ID}.iam.gserviceaccount.com" \
        --role=roles/storage.objectUser

And that’s all we need for the authorization setup. The only thing remaining to do is is configuring some enviroment variables.

Configuring repository Environment Variables

There are three sets of environment variables we need to configure. First we need to set the WIF environment variables, which will be used in the Google Auth step.

  • WIF_PROVIDER

    • Name: WIF_PROVIDER
    • Description: Workload Identity Federation configuration. Should be in the format projects/736537866288/locations/global/workloadIdentityPools/ci-cd/providers/github-actions.
    • Example: projects/0123456789/locations/global/workloadIdentityPools/ci-cd/providers/github-actions

  • WIF_SERVICE_ACCOUNT

    • Name: WIF_SERVICE_ACCOUNT
    • Description: Workload Identity Federation configuration. Recommended to have separate configuration for each environment.
    • Example: devops-svc@my-project-dev.iam.gserviceaccount.com

Then, whe have the backend configuration definition, which are mostly passed as --backend-config into tofu init

  • TF_BUCKET

    • Name: TF_BUCKET
    • Description: Backend configuration for OpenTofu. At least one of these needs to be environment-specific. Recommended to have separate buckets for each environment.
    • Example: my-tf-bucket-dev-213496087

  • TF_PREFIX

    • Name: TF_PREFIX
    • Description: Backend configuration for OpenTofu. If storing state for both environments in a single bucket, specify a different prefix or workspace for each environment.
    • Example: my-service-state

  • TF_WORKSPACE

    • Name: TF_WORKSPACE
    • Description: Backend configuration for OpenTofu (Optional). If storing state for both environments in a single bucket, specify a different prefix or workspace for each environment.
    • Example: dev-workspace

And finally we have the variables that are passed into as variables to tofu plan. You’ll maybe recognize these from the section on this guide about the terraform variables.

  • SERVICE

    • Name: SERVICE
    • Description: Name of the service. Used for naming deployed resources. Recommended to set as a Repository Variable for consistent naming of resources across environments.
    • Example: my-service

  • ENV

    • Name: ENV
    • Description: Used for namespacing resources to their specific environment. Also passed as an environment variable to the Cloud Run service.
    • Example: dev

  • PROJECT_ID

    • Name: PROJECT_ID
    • Description: Project where the application stack will be deployed. Recommend using a separate project per environment.
    • Example: my-project-dev

  • REGION

    • Name: REGION
    • Description: Region where the application stack will be deployed.
    • Example: us-central1

Conclusion

Now if you try to rerun the deployment job, you should have a function CI/CD pipeline that deploys resources with IaC and manages a prod and dev environments.

There are many things that I enjoy about this setup. One of them is that the power Terraform will allow your CI/CD pipeline to remain simple as your application infrastructure grows. If you get to the point that your application is composes of multiple microservices on Cloud Run, you can just copy paste the configuration (or create a module) with different build contexts that point to different deployment packages in you repository.
